The cable is used for public power distribution network 1~35KV.
The cable is used for public power distribution network 1~35KV.
Reference Standard NFC C33226, IEC60228, IEC60502-2
| Conductor Size | Stranding No. | Max. Conductor Resistance 20℃ | Conductor Dia. | Conductor Size | Stranding No. | Max. Conductor Resistance 20℃ | Conductor Dia. |
| mm2 | — | Ω/km | mm | mm2 | — | Ω/km | mm |
| 16 | 7 | 1.91 | 4.6~5.2 | 150 | ≥15 | 0.206 | 13.7~15.0 |
| 25 | 7 | 1.2 | 5.6~6.5 | 185 | ≥30 | 0.164 | 15.3~16.8 |
| 35 | ≥6 | 0.868 | 6.6~7.5 | 240 | ≥30 | 0.125 | 17.6~19.2 |
| 50 | ≥6 | 0.641 | 7.7~8.6 | 300 | ≥30 | 0.1 | 19.7~21.6 |
| 70 | ≥12 | 0.443 | 9.3~10.2 | 400 | ≥53 | 0.0778 | 22.3~24.6 |
| 95 | ≥15 | 0.32 | 11.0~12.0 | 500 | ≥53 | 0.0605 | 25.3~27.6 |
| 120 | ≥15 | 0.253 | 12.3~13.5 | 630 | ≥53 | 0.0286 | 28.7~32.5 |
| Table1-10KV (6/10KV) Single Core ,Aluminum Underground Cable | Table2-10KV (6/10KV) Three Core ,Twisted Aluminum Underground Cable | |||||||||
| Size | Insulation thickness | Outer Sheath Thickness | Approx. Cable Dia. | Approx. Cable Weight | Size | Insulation thickness | Outer Sheath Thickness | Approx. Cable Dia. | Approx. Cable Weight | |
| mm2 | mm | mm | mm | kg/km | mm2 | mm | mm | mm | kg/km | |
| 25 | 3.4 | 1.8 | 20.3 | 370 | 25 | 3.4 | 1.8 | 43.7 | 1117 | |
| 35 | 3.4 | 1.8 | 21.3 | 421 | 35 | 3.4 | 1.8 | 45.9 | 1270 | |
| 50 | 3.4 | 1.8 | 22.5 | 490 | 50 | 3.4 | 1.8 | 48.5 | 1480 | |
| 70 | 3.4 | 1.8 | 24.2 | 584 | 70 | 3.4 | 1.8 | 52.1 | 1761 | |
| 95 | 3.4 | 1.8 | 25.9 | 691 | 95 | 3.4 | 1.8 | 55.8 | 2087 | |
| 120 | 3.4 | 1.8 | 27.3 | 792 | 120 | 3.4 | 1.8 | 58.8 | 2392 | |
| 150 | 3.4 | 1.8 | 28.7 | 906 | 150 | 3.4 | 1.8 | 61.8 | 2735 | |
| 185 | 3.4 | 1.9 | 30.7 | 1051 | 185 | 3.4 | 1.9 | 66.1 | 3171 | |
| 240 | 3.4 | 2 | 33.3 | 1267 | 240 | 3.4 | 2 | 71.7 | 3826 | |
| 300 | 3.4 | 2 | 35.5 | 1485 | 300 | 3.4 | 2 | 76.5 | 4484 | |
| 400 | 3.4 | 2.2 | 38.7 | 1810 | – | – | – | – | – | |
| 500 | 3.4 | 2.2 | 41.7 | 2149 | – | – | – | – | – | |
| 630 | 3.4 | 2.4 | 45.7 | 2609 | – | – | – | – | – | |
| Table3-15KV (8.7/15KV) Single Core ,Aluminum Underground Cable | Table4-15KV (8.7/15KV) Three Core ,Twisted Aluminum Underground Cable | |||||||||
| Size | Insulation thickness | Outer Sheath Thickness | Approx. Cable Dia. | Approx. Cable Weight | Size | Insulation thickness | Outer Sheath Thickness | Approx. Cable Dia. | Approx. Cable Weight | |
| mm2 | mm | mm | mm | kg/km | mm2 | mm | mm | mm | kg/km | |
| 25 | 4.5 | 1.8 | 22.4 | 433 | 25 | 4.5 | 1.8 | 48.2 | 1305 | |
| 35 | 4.5 | 1.8 | 23.4 | 486 | 35 | 4.5 | 1.8 | 50.4 | 1467 | |
| 50 | 4.5 | 1.8 | 24.6 | 559 | 50 | 4.5 | 1.8 | 53 | 1687 | |
| 70 | 4.5 | 1.8 | 26.3 | 657 | 70 | 4.5 | 1.8 | 56.7 | 1983 | |
| 95 | 4.5 | 1.8 | 28 | 769 | 95 | 4.5 | 1.8 | 60.3 | 2322 | |
| 120 | 4.5 | 1.9 | 29.6 | 883 | 120 | 4.5 | 1.9 | 63.8 | 2666 | |
| 150 | 4.5 | 1.9 | 31 | 1001 | 150 | 4.5 | 1.9 | 66.8 | 3021 | |
| 185 | 4.5 | 2 | 33 | 1152 | 185 | 4.5 | 2 | 71.1 | 3477 | |
| 240 | 4.5 | 2.1 | 35.6 | 1376 | 240 | 4.5 | 2.1 | 76.7 | 4156 | |
| 300 | 4.5 | 2.1 | 37.8 | 1600 | 300 | 4.5 | 2.1 | 81.4 | 4834 | |
| 400 | 4.5 | 2.2 | 40.8 | 1925 | – | – | – | – | – | |
| 500 | 4.5 | 2.3 | 44 | 2285 | – | – | – | – | – | |
| 630 | 4.5 | 2.4 | 47.8 | 2743 | – | – | – | – | – | |
| Table5-24KV (12/20KV) Single Core , Aluminum Underground Cable | Table6-24KV (12/20KV) Three Core ,Twisted Aluminum Underground Cable | |||||||||
| Size | Insulation thickness | Outer Sheath Thickness | Approx. Cable Dia. | Approx. Cable Weight | Size | Insulation thickness | Outer Sheath Thickness | Approx. Cable Dia. | Approx. Cable Weight | |
| mm2 | mm | mm | mm | kg/km | mm2 | mm | mm | mm | kg/km | |
| 25 | 5.5 | 1.8 | 24.4 | 503 | 25 | 5.5 | 1.8 | 52.6 | 1518 | |
| 35 | 5.5 | 1.8 | 25.4 | 559 | 35 | 5.5 | 1.8 | 54.7 | 1689 | |
| 50 | 5.5 | 1.8 | 26.6 | 636 | 50 | 5.5 | 1.8 | 57.3 | 1919 | |
| 70 | 5.5 | 1.8 | 28.3 | 739 | 70 | 5.5 | 1.8 | 61 | 2231 | |
| 95 | 5.5 | 1.9 | 30.2 | 865 | 95 | 5.5 | 1.9 | 65.1 | 2612 | |
| 120 | 5.5 | 1.9 | 31.6 | 975 | 120 | 5.5 | 1.9 | 68.1 | 2943 | |
| 150 | 5.5 | 2 | 33.2 | 1107 | 150 | 5.5 | 2 | 71.5 | 3341 | |
| 185 | 5.5 | 2 | 35 | 1253 | 185 | 5.5 | 2 | 75.4 | 3785 | |
| 240 | 5.5 | 2.1 | 37.6 | 1486 | 240 | 5.5 | 2.1 | 81 | 4487 | |
| 300 | 5.5 | 2.2 | 40 | 1728 | 300 | 5.5 | 2.2 | 86.2 | 5221 | |
| 400 | 5.5 | 2.3 | 43 | 2062 | – | – | – | – | – | |
| 500 | 5.5 | 2.4 | 46.2 | 2432 | – | – | – | – | – | |
| 630 | 5.5 | 2.5 | 50 | 2903 | – | – | – | – | – | |
| Table7-33KV, 36KV (18/30KV) Single Core , Aluminum Underground Cable | Table8-33KV, 36KV (18/30KV) Three Core ,Twisted Aluminum Underground Cable | |||||||||
| Size | Insulation thickness | Outer Sheath Thickness | Approx. Cable Dia. | Approx. Cable Weight | Size | Insulation thickness | Outer Sheath Thickness | Approx. Cable Dia. | Approx. Cable Weight | |
| mm2 | mm | mm | mm | kg/km | mm2 | mm | mm | mm | kg/km | |
| 25 | 8 | 1.9 | 30 | 733 | 25 | 8 | 1.9 | 64.6 | 2215 | |
| 35 | 8 | 1.9 | 31 | 799 | 35 | 8 | 1.9 | 66.8 | 2412 | |
| 50 | 8 | 2 | 32.4 | 894 | 50 | 8 | 2 | 69.8 | 2702 | |
| 70 | 8 | 2 | 34.1 | 1013 | 70 | 8 | 2 | 73.5 | 3058 | |
| 95 | 8 | 2.1 | 36 | 1155 | 95 | 8 | 2.1 | 77.5 | 3488 | |
| 120 | 8 | 2.1 | 37.4 | 1277 | 120 | 8 | 2.1 | 80.6 | 3857 | |
| 150 | 8 | 2.2 | 39 | 1423 | 150 | 8 | 2.2 | 84 | 4296 | |
| 185 | 8 | 2.2 | 40.8 | 1585 | 185 | 8 | 2.2 | 87.9 | 4788 | |
| 240 | 8 | 2.3 | 43.4 | 1840 | 240 | 8 | 2.3 | 93.5 | 5558 | |
| 300 | 8 | 2.4 | 45.8 | 2103 | 300 | 8 | 2.4 | 98.7 | 6355 | |
| 400 | 8 | 2.5 | 48.8 | 2463 | – | – | – | – | – | |
| 500 | 8 | 2.6 | 52 | 2861 | – | – | – | – | – | |
| 630 | 8 | 2.7 | 55.8 | 3365 | – | – | – | – | – | |
Our cables, wires, conductors are usually packed in wood drum, Iron-wooden drum. Steel reel will also be used if required by client. For some short length, such as 50m, 150m, 300m, the conductor can also be packed in coil.
Product standard, Conductor Size, Quantity, Sea port/Airport for delivery, etc.
Usually we will quote to you within 24 hours after get your detailed inquiry information
We have exported to 100+ countries/area. We have rich export experience and will try our best to serve you and meet your needs. You can contact us for detailed communications.
Normally we offer EXW,FCA,FOB,CNF,CIF according to customer requirements.
According to different order quantity, the lead time is different. Normally it is 7- 30 days for production. For large quantities, the goods will be shipped in partial times according to schedule.
