CLX Type P-OS Type ITC/PLTC Armored Thermoset Instrumentation Cable is a specialized type of cable used in environments that require enhanced protection and performance.
Sheath: PVC,flame resistance;
Description: CLX Type P-OS Type ITC/PLTC Armored Thermoset Instrumentation Cable is a specialized type of cable used in environments that require enhanced protection and performance.
Construction:
Conductor: Bare soft annealed copper;
Insulation: X-Olene (XLP);
Cable Shield: Aluminum/Polyester tape over lapped to provide 100% coverage, and a 7-strand tinned copper drain wire, same size as conductor.
Inner Jacket: PVC,flame resistance;
Sheath: PVC,flame resistance;
Application: Type CLX P-OS (Pair/Triad - Overall Shield) instrumentation cables are designed for use as instrumentation, process control, and computer cables in ITC non-classified or labeled circuits up to 150 volts and 5 amps (750VA) and in Class 2 or 3 Power-Limited circuits where shielding against external interference is required, but shielding against interference among groups is not required; indoors or outdoors; in wet or dry locations with conductor operating termperatures up to 90°C;in cable trays; in raceways; supported by a messenger wire; under raised floors; for direct burial.
| Number of Pairs | Inner Jacket Thickness-mils | Inner Jacket Nominal O.D. – Inches | Outer Jacket -(mils) | C-L-X O.D. – Inches | Nominal Cable O.D. – Inches | Cross-Sectional Area (sq in) | Approx Net Weight (lbs/1000’) |
| 2 | 40 | 0.37 | 50 | 0.58 | 0.69 | 0.37 | 229 |
| 4 | 50 | 0.49 | 50 | 0.71 | 0.82 | 0.53 | 292 |
| 8 | 60 | 0.65 | 50 | 0.89 | 1 | 0.79 | 404 |
| 12 | 60 | 0.76 | 50 | 1.02 | 1.13 | 1 | 551 |
| 16 | 60 | 0.87 | 50 | 1.11 | 1.22 | 1.17 | 652 |
| 24 | 70 | 1.01 | 50 | 1.34 | 1.45 | 1.65 | 916 |
| 36 | 70 | 1.24 | 60 | 1.56 | 1.69 | 2.24 | 1212 |
| 50 | 80 | 1.47 | 60 | 1.83 | 1.96 | 3.02 | 1700 |
Our cables, wires, conductors are usually packed in wood drum, Iron-wooden drum. Steel reel will also be used if required by client. For some short length, such as 50m, 150m, 300m, the conductor can also be packed in coil.
Product standard, Conductor Size, Quantity, Sea port/Airport for delivery, etc.
Usually we will quote to you within 24 hours after get your detailed inquiry information
We have exported to 100+ countries/area. We have rich export experience and will try our best to serve you and meet your needs. You can contact us for detailed communications.
Normally we offer EXW,FCA,FOB,CNF,CIF according to customer requirements.
According to different order quantity, the lead time is different. Normally it is 7- 30 days for production. For large quantities, the goods will be shipped in partial times according to schedule.
