Know more about CN Cable’s leaky cable

2024-07-26

Leaky coaxial cable is abbreviated as leaky cable. It is a kind of coaxial cable with slots arranged periodically or non-periodically on the outer conductor.

Leaky coaxial cable is abbreviated as leaky cable. It is a kind of coaxial cable with slots arranged periodically or non-periodically on the outer conductor. A part of the electromagnetic wave energy transmitted along the inside of the cable can be radiated or coupled through the slots on the outer conductor to the outer space, at the same time, the external signal can also be coupled to internal leaky coaxial cable from the opposite direction for reverse transmission, realizing omni-directional bidirectional wireless communication with the external space, so the leaky coaxial cable has both the function of transmitting signals and receiving/transmitting radio, it has the advantages that a discrete antenna cannot be replaced in a wireless communication system. It also has the advantages of uniform signal coverage,less electromagnetic pollution, long transmission distance, and simple cable laying.

Leaky coaxial cables can be used in places where general communication antennas are difficult to function, especially in places where the discrete antennas of mobile communication systems cannot provide sufficient field strength, such as mountainous, hills, tunnels, underground railways, mines, underground buildings, shopping malls,or other blind areas of electromagnetic field propagation. In these areas, due to the narrowness and obstruction of the surrounding environment, the antenna coverage is greatly restricted, and the leaky coaxial cable can provide uniform field strength because it is very close to the covered object and the signal radiation direction is perpendicular to the radiation environment. For wireless signal receiving devices, leaky coaxial cables are the best wireless coverage method.

CN Cable's leaky coaxial cable products are internationally exported to India, Iran, South Korea, Angola,Costa Rica, Australia, Norway,UAE,Indonesia, the United States, Israel, Uganda, Dubai, Thailand, Bangladesh,Macedonia, Canada and other countries, and are well received by users.
